Search Magnets – Part No.: HSPNS-F300
Diameter D – 94 mm
Height H – 20 mm
Pull power: 300 kg
Weight: 1.15 kg
The thread of bolts: M8
One-way Eyebolts included.
With galvanized body
Magnet material: NdFeB
Magnet shape: Pot, cylinder, ring
Magnet coating: Nickel (ni-cu-ni)
Max. work temperature: +80℃
300kg Holding & Retrieving Neodymium Search Magnet
Product Description
300kg One-side Holding & Retrieving Neodymium Search Magnet, One-way Eyebolt NdFeB Pot Magnet, Rare Earth Neodymium Pot Magnet, Fishing Magnet, Underwater Retrieving Recovery Magnet, Powerful Search Magnet China Supplier
300kg Holding & Retrieving Neodymium Search Magnet Part No. HSPNS-F300 by HSMAG Features :
Material: Zinc or Nickel Coating, Housing steel and Magnetic core sintered neodymium pot magnet with one-side eyebolt.
Version: Housing, galvanized. Magnet, Ni coated or Zn coated
Note: Shallow pot magnets, These magnets are pressed or glued into the receiving holes.
Hairline cracks in the magnetic material are unavoidable for technical reasons in the D=94 mm version. They do not impair the attracting function of the magnets in any way.
Temperature range: max. 80°C.
Neodymium Pot magnet with Threaded Stud. Complete with EYEBOLT. Super Strong Treasure Salvage Neodymium Magnet
The strong Neodymium magnet is encased in steel which concentrates the magnetic pulling power to the front face.
Please note this pull figure can only be achieved when using the magnet on a flat piece of steel around 25mm thick. When used on thin sections most of the magnetic field will pass through the item and not grip anything. The pull on thin sections will therefore be much less than on thicker items.
These magnets are approximately 10 times stronger than traditional ‘red’ magnets.
Tip:
1. Retrieving Neodymium Magnets should Keep away from Ironware and some easily magnetized iron products, such as monitors, bank cards, computers, televisions, mobile phones and other
2. Strong magnets should be stored in a dry, heated environment, and need to use of plastic, wood, cardboard, foam to separated and wrapped.
3. Magnets might be interested in water meter ,Electric meter, gas meter and some metering equipment exist some inaccurate affect (Such as : if magnets placed near the meter, the meter will slow down)
We can design and manufacture A Wide Range of Pot Magnets according to clients requirements.
Pot magnets (Mounting Magnets) are made up of magnets (NdFeB, SmCo, AlNiCo or Hard Ferrite) and other spare parts, such as metal, plastic, rubber and other components. Sometimes Pot magnets can meet some special requirements while a single magnet can not do. In the meantime, using pot magnets can save more cost than just using magnets and gain the same purpose.
Part No. | Sizes (mm) | Break Force (kg) | Dead Weight (kg) | ||
---|---|---|---|---|---|
D | H | M | |||
HSPNS-F100 | 48 | 11 | 8 | 100 | 0.21 |
HSPNS-F120 | 60 | 15 | 10 | 120 | 0.41 |
HSPNS-F200 | 75 | 19 | 10 | 200 | 0.73 |
HSPNS-F300 | 94 | 20 | 10 | 300 | 1.15 |
HSPNS-F400 | 116 | 20 | 10 | 400 | 1.58 |
HSPNS-F600 | 136 | 25 | 12 | 600 | 2.80 |
For Fishing, Retrieving and Holding
